Holographic Transparent LED Screen — H Series
The Gleam LED H Series is a holographic transparent LED screen designed for glass storefronts, retail environments and architectural applications. With a slim 1.8 mm profile, lightweight construction and flexible module design, the H Series integrates digital content with glass while maintaining visibility and natural light.
Available in multiple pixel pitches, transparency levels and brightness configurations, the H Series can be selected according to viewing distance, ambient light, transparency requirements and installation conditions.
View Specifications Request a Project AssessmentWhat Is a Holographic Transparent LED Screen?
A holographic transparent LED screen is a transparent LED display designed to present digital visual content while allowing the underlying glass and surrounding environment to remain visible. Unlike conventional opaque LED screens, transparent LED displays allow light and sightlines to pass through the display structure.
The Gleam LED H Series is designed for applications where transparency, visual impact and architectural integration are important. Its lightweight and flexible module design supports different glass and architectural applications, subject to the specific project requirements.
Holographic Transparent LED Features
H Series configurations provide up to 95% transparency, helping maintain visibility and natural light through glass-based installations.
Transparent display construction allows digital content to appear visually integrated with the glass environment, supporting immersive and floating visual experiences.
The H Series supports 16-bit grayscale image reproduction, providing detailed tonal transitions for digital content.
H Series display modules are designed with lightweight construction, with published configurations at approximately 5–6 kg/m².
The slim module profile allows the display to be integrated closely with glass surfaces without the visual bulk associated with conventional LED structures.
Flexible module construction supports curved architecture and custom-shaped glass applications, subject to project requirements.
Architectural Display Advantages
H Series configurations provide up to 95% transparency, allowing the display to maintain visibility and natural light through glass-based environments.
The transparent display structure is designed to integrate with glass surfaces while preserving the visual character of the surrounding architecture.
Flexible modules can be configured for curved or custom-shaped applications where the installation surface requires a non-standard display form.
The H Series uses a lightweight display construction, with published configurations at approximately 5–6 kg/m².
Holographic LED Screen Applications
The H Series is designed for commercial and architectural environments where digital content needs to coexist with glass, visibility and existing sightlines.
Retail Storefronts
Integrate digital campaigns, product visuals and branded content across storefront glass while maintaining visibility into the retail environment.
Luxury Retail & Jewellery
Create high-impact visual experiences across glass surfaces where transparency and premium presentation are important.
Automotive Showrooms
Display campaigns, vehicle launches and brand content on showroom glass without creating a conventional opaque video wall.
Shopping Malls
Use transparent digital displays across storefronts, commercial interiors and selected architectural glass environments.
Architectural Glass
Integrate digital media with glass architecture while maintaining the visual character and openness of the surrounding environment.
Experience Centres & Exhibitions
Create immersive digital experiences using transparent displays and visual content that interacts with the surrounding environment.
H Series Technical Specifications
BL: Black Light | WL: White Light
| Parameter | H2 Series | H3 Series | H6 Series |
|---|---|---|---|
| LED Specification | 1515 | 2121 | 2121 |
| Pixel Pitch (mm) | 2.5-2.5 | 3.91-3.91 | 6.25-6.25 |
| Pixel Density (dot/m²) | 160,000 | 65,536 | 25,600 |
| Transparency Rate | 85% | 92% | 95% |
| Brightness (cd/m²) | ≥1000 (BL) | ≥3000 (BL) / 4500 (WL) | ≥5000 (WL) |
| Max Power (w/m²) | 608 | 520 - 684 | 440 - 552 |
| Avg Power (w/m²) | 244 | 208 - 274 | 176 - 221 |
| Color Temp (K) | 3000~10000 | 3000~10000 | 3000~10000 |
| Frame Rate | 60~120 Hz | 60~120 Hz | 60~120 Hz |
| Lifespan | ≥ 100,000 Hours | ||
| Input Voltage | AC100~240V 50/60Hz | ||
| Protection Degree | IP20 | ||
| Working Temp | -20℃ ~ 50℃ | ||
| Installation Method | PCB Side Glued | LED/PCB Side Glued, Hanging | LED/PCB Side Glued, Hanging |
Statement: The relevant parameters in the table are subject to real-time update, and the data is for reference only. Gleam LED reserves the right to upgrade specifications without further notice.
H Series Installation & Maintenance
Installation requirements depend on the glass configuration, display dimensions, mounting conditions and project environment. The selected H Series configuration should be evaluated together with the installation surface and required service access.
- Glass dimensions and configuration
- Display dimensions and module arrangement
- Viewing distance and viewing direction
- Ambient light and daylight exposure
- Power and data cable routing
- Mounting and structural requirements
- Access for inspection and servicing
H Series vs Other Gleam Transparent LED Solutions
Gleam LED offers multiple transparent LED configurations for different architectural and commercial requirements. The most suitable solution depends on the application, glass environment, viewing conditions and installation requirements.
| Requirement | H Series | LUCID | INV |
|---|---|---|---|
| Holographic / spatial visual effect | Yes | — | — |
| High transparency | Yes | Yes | Yes |
| Glass applications | Yes | Yes | Yes |
| Flexible module design | Yes | — | Yes* |
| Curved / custom applications | Yes* | Project dependent | Yes* |
| Retail / storefront applications | Yes | Yes | Yes |
* Suitability depends on the specific product configuration and project requirements.
Explore Transparent LED Solutions
Compare Gleam LED transparent display technologies and identify the configuration that best fits your project requirements.
Holographic Transparent LED FAQs
What is a holographic transparent LED screen?
How transparent is the H Series?
Can the H Series be installed on glass?
Can H Series transparent LED be used in daylight?
Is the H Series suitable for curved glass?
How much does a holographic transparent LED screen cost?
What information is required for an H Series project?
Planning a Holographic Transparent LED Installation?
Share your glass dimensions, project location, viewing requirements and site photographs with Gleam LED to discuss the appropriate H Series configuration for your application.
Request a Project Assessment
